Introduction

Palm oil mill effluent (POME) is a viscous brown liquid with fine suspended solids at pH between 4 and 5¹and a highly polluting wastewater that directly and indirectly contaminates the environment.²摘要梨果差别很大的化学性质hout the year because of mill operations and seasonal cropping.³Atmospheric methane concentrations incredibly increased by 30% in the last 25 years.⁴Net carbon emission from POME is approximately 1.4 × 106 tons per year.⁵Assuming a mean annual increase of 29% as experienced from 1990 to 2004,⁶the estimated CH4 gas emission may be 0.502 × 106 tons in the year 2020. Certified emission reduction (CER) can be obtained by using methane gas as a renewable energy.⁷

At high organic loadings or at natural environment temperatures, the insoluble organic degradation of the effluent tends to accumulate within the granules or sludge density region of the ponds, leading to granule destabilization or inhibition of granule formation.⁸To date, 85% of POME treatment in Malaysia is based on an anaerobic and facultative ponding system, which is followed by another system consisting of an open-tank digester coupled with extended aeration. For every ton of treated POME, an average of 5.5 kg of CH₄(or approximately 36% of biogas) is emitted from open digesting tanks.³Anaerobic digestion is the most suitable method for the treatment of effluents containing high concentration of organic carbon and thus producing biogas.⁹A typical biogas would comprise 60-70% methane, 30-40% carbon dioxide, 0-0.1% hydrogen sulphide, and 0-10% hydrogen.¹⁰Recently, both conventional single-phase and high-rate two-phase anaerobic digestion systems have been widely used, for the production of biogas-methane from various substrates, such as the organic fraction of the municipal solid waste, POME, food waste, waste-activated sludge, and sugar beet silage.^11,12

Periodic research has been performed to find amicable solutions for POME management.^13-15The presence and activity of microorganisms in POME treatment are vital to the process. With regard to microbial degradation of POME effluent, biodegradation phenomenon is crucial. Therefore, the steady-state models are basically able to predict the parameters that have been considered in mass balance relations but are unable to estimate the other interrelated effluent quality parameters.¹⁶Biodegradation is a metabolism-independent consumption of organic to living cells, nonliving biomass, or microbial extracellular polymers.^17,18Specific metabolic pathways resulting in bio-precipitation of organic molecules or their mechanisms of degradation have been provided elsewhere.^19,20Moreover, surface exposure of organic-binding microbes improves organic-binding properties of microorganisms based on degradation and microbial metabolic activities.²¹Binding of organic molecules with microbes is known to reduce the COD and selected biogas (CH₄, CO₂, and VFAs)²²Yacob et al., 2006a S. Yacob, M.A. Hassan, Y. Shirai, M. Wakisaka and S. Subash, Baseline study of methane emission from anaerobic ponds of palm oil mill effluent treatment, Science of the Total Environment 366 (2006), pp. 187–196. Article | PDF (357 K) | View Record in Scopus | Cited By in Scopus.¹³Consequently, the removal of COD and treatment of POME effluent with anaerobic and aerobic system also are affected, although many studies have shown that COD can be removed in POME treatment processes.²³

During POME treatment, a large amount of sludge is produced (approximately 35% of the treated wastewater). The Malaysian government proposed and legalized standards for POME discharge into watercourses.²⁴The results of a one-year evaluation on the POME degradation was using aerobic, anaerobic digestion of VFA, and removal of COD in terms of selected biogas (CH₄, H₂, and CO₂) by an OT and CR treatment system. The aim of the study were to compare COD, VFA, and biogas contents in the influent and effluent wastewater and to examine the COD and biogas contents in the effluent before and after digestion and compare the performance of our designed treatment system with LSHC POME treatment plant (LSHC-WTP).

Materials and methods

Description of the Gambang POME treatment plant

The main objective is to reduce the level of organic pollution and COD removal from POME before discharging it to the environment. Treatment processes were used are shown in Fig. 1.

Sample collection

每月收集fi原始梨果样本ve sample from LHSC-Palm Oil Mill, situated in the state Pahang, Malaysia. The features and composition of the POME used are summarized in Table 1, which shows the average values of five replicate analyses for each parameter. In comparing the biogas contents in influent and effluent samples (collected from locations 1, 4, 5, and 6), their removal from the influent wastewater was assessed. Because accurate matching of influent and effluent samples was difficult because of large volumes of wastewater or treated sludge, 10 influent and effluent sample pairs were taken to obtain a composite grab sample. Five samples were collected once a month for one year. During each sampling day, three composite grab samples were collected from the influent stream using an automatic wastewater sampler, whereas sample collection from the effluent was done manually approximately 21 h later; this is an approximate time required for the influent stream to pass through all the wastewater treatment operation units between locations 1, 4, 5, and 6 was mentioned in Fig. 1. Grab samples of mixed sludge (location 4) and digested sludge (location 5) also were collected manually. Digested sludge biogas samples were collected 28 days (retention time of sludge in the anaerobic digester) after collecting the mixed sludge sample, which was the influent, into the TP and CR anaerobic digesters. During the period when these investigations were being conducted, the anaerobic digesters (TP and CR) were yet in operation (Fig. 1). To avoid deterioration or contamination of samples, sampling procedures and sample preservation were done according to the Standard Methods for the Examination of Water and Wastewater.²⁵Characteristics of raw and pre-treated POME are provided in Table 1 and 2, respectively.

Table 1: Physio-chemical characteristics (POME)

* All parameters are in g L^-1except pH^aas TSS^bas total nitrogen

Table 2: Composition and characteristics of the pre-treated POME

Analytical Analysis

All the tests for the samples were analyzed according to the guidelines of the American Public Health Association²⁶for the examination of water and wastewater. Biogas yield was measured with a wet gas meter (W-NK-O.SA, Shinagawa). Gas samples were obtained through an inverted funnel placed above baffles near the top of the reactor. Biogas composition was determined using a gas chromatograph (GC-8A, Shimadzu, Kyoto) with a thermal conductivity detector equipped with a steel column packed with WG-100 (GL Sciences, Tokyo) at 50°C. Volatile fatty acids (VFAs) were determined with a gas chromatography (W-NK-O.SA, Shinagawa) equipped with a 2 m × 4 mm glass column packed with Suplocopor (100-120 mesh) coated with 10% Fluorad FC 431. The temperatures of the column, the injection port, and the flame ionization detector were 130, 220, and 240°C, respectively. Effluent and biogas production rates were measured and analyzed weekly, whereas biomass concentration was analyzed biweekly for each loading rate.

Results and Discussion

COD removal in TP and CR

Fig. 2 presents the average COD removal efficiencies in %. The values were calculated based on the 12-month COD contents in the influent and effluent in TP and CR. The variations in COD concentration and removal in CR was greater than those in the TP (Fig. 2). In the latter case, variations in the concentration of COD in primary treatment lead were sharper than those in the secondary treatment. The maximum degradability rate of COD 59.9% was faster and COD removal was found to be 85.5% by CR, whereas that in the TP was only 70%, which was varying and higher than those of primary treatment where COD removal is approximately 53% Table 3. These trends were observed throughout the study period of 12 months, indicating that these COD originated from the same respective sources. COD degradability depends on the CH4 emission rate in both TP and CR. An average of 0.109 g of CH₄was produced from a 1 g of COD (Fig. 2). During the operation an average COD of POME was 45000 ± 2189 mg/l while the CR treated POME was 2435±1176 mg/l.¹⁸

Table 3: Results obtained during primary treatment of POME

The COD removal occurs in both primary treatment (where a portion of organics is adsorbed on to the particles) and secondary biological treatment (where COD is removed by anaerobic digestion of volatile fatty acids).⁸Biological treatment systems are chiefly designed for the removal of organic carbon by activated sludge microorganisms. Therefore, removal of organics by these systems may be regarded as a side benefit, minimizing the amount of carbon emission and sludge disposal and producing biogas and methane.^9,20

如图2所示,COD浓度在两种tanks was almost the same until September, but open tank showed a comparatively low COD concentration in October and November 2011, perhaps because there was more rainfall during these months in which COD concentration was reduced because of rain water dilution in the open tank. On the other hand, the closed tank was obviously not affected by rainfall because of closed anaerobic environment.²⁷studied pollution control technologies for the treatment of POME and reported similar observations.

Biogas production, CH4 and CO2

The variation in the contents of CH4 (Fig. 3) and CO2 (Fig. 4) in the effluent was more pronounced. The variation in the content of CH4 was the most pronounced, whereas that of VFA and CO2 varied in the first six months and later remained stable, with few exceptions. These observed stable contents of CH4, CO2, and biogas in the effluent corresponded well with their respective stable contents in the influent stream.

VFA转换和沼气生产受到影响by the treatment system itself. For example, when removal efficiencies are calculated, only the COD/VFA contents in the influent stream are considered in comparison with that in the effluent. However, from the conceptual model shown (Fig. 1), the biological treatment system is potentially overloaded with VFA contained in the returned streams, namely, recycled activated sludge and returned wastewater. The treatment and degradation of VFA in the treatment systems seem to be influenced by the following mechanisms: (1) acetogenesis, conversion of butyrate to acetate and hydrogen; (2) methanogenesis, cleavage of acetate to CH₄and CO₂; and (3) reduction of CO₂to CH_4.^28,29The effects of VFA contents were in the return streams (Fig. 5) on the wastewater influent and effluent COD/VFA contents (consequently, on their removal efficiencies). In addition, it is not known which organic and inorganic components of the sludge are anaerobically degraded and how such degradation processes affect the contents of CH₄and COD in the sludge.

Volatile fatty acid concentration

Fig. 5 shows the VFA concentrations in TP and CR during a one-year period. From August to July, the VFA concentration in both tanks was increased slightly, although the CR had higher VFA concentration because of anoxic treatment conditions. However VFA reduction from 790 to 230 mgl^-1; this reduction could not increase the biogas production because dilution of normal water during biodegradation of organic matter lowers the reaction rate during the treatment process.

The VFA concentrations in the CR were relatively high (400-1240 mgl^-1) because the treatment process is totally anaerobic. The high concentration of VFA in the closed tank is due to the faster reaction rate in the absence of oxygen. Moreover, the conversion of acidogenesis into acetogenesis requires less time compared with that during partial anaerobic conditions.

When the VFA concentrations in the two tanks were compared, the organic decomposition under full anaerobic conditions was observed to be stronger than that under partial anaerobic condition (Fig. 5). Furthermore, by comparing the biogas production at the same time, the closed anaerobic tank produced more gas than the open tank, although VFA concentration in the closed tank was relatively higher than that in the open tank. Fatty acid accumulation inhibits biogas production as reported in earlier studies; however, up to a certain level of VFA accumulation (2,000-3,000 mgl^-1), biogas production is not disturbed.³⁰Because of this, the biogas production rate in both tanks was almost low, but it was continued because of the low concentration of VFA in the organic matter.³¹found low biogas yield and organic matter removal because of the accumulation of inhibiting substances, such as volatile fatty acids.³²reported that COD removal was greater than VFA removal at the same pH and initial concentrations.²⁰Furthermore, VFA removal efficiency is affected not only by VFA species and concentration but also by other conditions, such as operating parameters and physical, chemical, and biological factors.³³For example, it is known that VFA removal by activated sludge is dependent on dissolved organic matter³and pH,^35,36whereby the removal efficiency increases with increasing pH until fatty acids precipitate as hydroxides. Moreover, biological wastewater treatment is normally conducted at pH 7–9. A major limitation of the anaerobic digestion of fruit and vegetable wastes in single-stage system is the rapid production of volatile fatty acids attributed to pH decrease during acidification that stressed and inhibited the activity of methanogenic bacteria.²⁹The relationship between influent COD contents and their removal efficiencies (Fig. 2) is consistent with the findings of other researchers^22,37who observed that COD and VFA removal efficiencies were directly proportional to influent concentrations.

Comparison of TP and CR treatment

The waste sludge from primary and secondary treatment processes is stabilized by anaerobic digestion, which involves microbial decomposition of organic and inorganic matter. In the treatment plant investigated, the mixed sludge was introduced in the TP at intervals, retained in the digester for 38 days, and then intermittently disposed of as digested sludge. COD in the sludge is present as organic compound, precipitates in the sludge flocks, complexes of soluble organics and biopolymers, and degraded soluble organics in the microbial cells [38]Brown and Lester, 1979. M.J. Brown and J.N. Lester, Metal removal in activated sludge: the role of bacterial extracellular polymers. Water Research 13 (1979), pp. 817–837. Abstract | PDF (2013 K) | View Record in Scopus | Cited By in Scopus (120). Fig. 2 and 5 show the results of COD and VFA of organic contents in both undigested and digested sludge. Both streams were characterized by highly fluctuating COD, VFA, and organic contents. Moreover, TP and CR digestion caused a decrease in TSS content in Fig. 6 that mean COD and VFA reduction on dry weight basis. The reduction in TSS contents in the effluent from 3615 to 1026 mgl^-1by TP and from 3617 to 438 mgl^-1by CR. After treatment of POME by CR the reduction of TSS approximately 65% means this technique reduce the burden of sludge in our environment. (Fig. 6) and organic matters are degraded into end products including CH₄, CO₂, N₂, H₂S, and some trace gases [39].

Because the determination of CH₄contents was based on COD reduction, the reduction of such organic and inorganic matters probably caused the observed increase in CH₄contents in the CR is more than TP, where as the degradation of COD in TP 58% and 85% in CR.⁴⁰indicated that the digestibility of organic components in the POME was in the following order: VFA422. Furthermore, the volatilization/solubilization of organics to the atmosphere from activated sludge systems also is known.⁴¹Such organic losses, although probably not a major factor, could have contributed to the inconsistency and variation in CH₄and CO₂content increases in the digested sludge.⁸investigated the treatment of POME using aerobic oxidation based on an activated sludge process. A possible reason for the increased removal of organic matter as well as oil and grease in the anaerobically digested sample was the presence of partially degraded organic and oil molecules, making them more amenable to aerobic digestion.

Fig. 3 show the average CH₄contents in undigested sludge. The increase in the content of VSS, which was the highest in the undigested sludge, was seemingly the lowest. Also, the content of CH₄, which was the lowest in the undigested sludge, increased more (approximately 97%) than that of the other parameters. As per survey a total amount of POME was discharge 235640 t in 2005 and COD was 45000 ± 2189 mgl^-1. After the treatment of POME by TP sludge was 506±254 and CR 354±127 gl^-1in l^-1of POME. This is best techniques to evaluate the treatment of by TP and CTE to CH₄production g^-1of COD and sludge management. In principle, the results of this study indicate that LHSC meets the compliance limits (COD, VFA, CH₄and TSS) for treated wastewater in accordance with the decree issued by the Malaysian Ministry of Environmental Protection about the characteristics of wastewater for disposal to water or land.

Conclusions

For the wastewater treatment system investigated, when the contents of COD and VFA are equal to 19.9 and 1240 mgl^-1, respectively, their reduction is insignificant. Thus, the COD removal is directly proportional to the influent concentrations. The reduction of COD contents was in the following increasing order: CH₄2, which directly corresponded to their COD initial influent wastewater contents. A relation was also established between TP and CR for VFA reduction rates where 110 mg/l in CR, where as in TP 570 ml^-1in November month was observed. The investigated CR system meets the compliance limits for treated wastewater. While for every g of COD of POME discharged, an average of 0.106 l of CH₄will be produced from the CR compared to TP 0.072 l of CH₄. The results presented herein indicate that a long term observation is crucial to determine the CH₄POME (t^-1d) CH₄(t^-1d). Relationship between CH₄从VFA sh减少86%owing high rate degradability rate of POME through our system. However, after treatment of POME by CR the reduction of TSS approximately 65% means this technique reduces the burden of sludge in our environment.

Acknowledgement

The authors thank the deanship of scientific research (DSR) at King Saud University (KSU) for its funding of this research through the research group project no. RGP-VPP-316.

References

1. 国民生产总值Najafpour, A.A.L. Zinatizadeh境穆罕默德,M.H. Isa, H.Nasrollahzadeh, High rate anaerobic digestion of palm oil mill effluent in an upflow anaerobic sludge-fixed film bioreactor,Process Biochemistry41, 370–379, (2006).

2. P.E. Poh, M.F. Chong, Development of anaerobic digestion methods for palm oil mill effluent (POME) treatment,Bioresour. Technol.100(1), 1–9 (2009).

3. M.A. Latif, R. Ghufran, Z.A. Wahid, A. Ahmad, Integrated application of upflow anaerobic sludge blanket reactor for the treatment of wastewaters,Water Research45, 4683-4699, (2011).

4. Intergovernmental Panel on Climate Change (IPCC). The physical science basis. contribution of working group-1 to the fourth assessment report of the IPCC, New York, Cambridge.http://ipcc-wg1. ucar.edu/wg1/wg1-report.html, 2007.

5. I.E. Henson, Modelling carbon sequestration and greenhouse gas emissions associated with oil palm cultivation and land-use change in Malaysia—a re-evaluation and a computer model.MPOB Technology, -No 31, May 2009.

6. M.B. Wahid, C.K. Weng, C.Y. May, C.M. Chin, The need to reduce national Greenhouse gases emissions: oil palm Industry’s role,J. of Oil Palm Resear. (Special Issue),1-23, (2006).

7. S.L. Tong, A.B. Jaafar, POME Biogas capture, upgrading and utilization,Palm Oil Engineering Bulletin.78, 11–17, (2006).

8. K. Vijayaraghavan, D. Ahmad, M.E. Abdul Aziz, Aerobic treatment of palm oil mill effluent,J. of Environ. Management.82, 24–31, (2007).

9. A. Ahmad, R. Ghufran, Z.A. Wahid, Method for use in Palm oil mill effluent (POME) treatment U.S. Patent No.20120040442- A1-(2012).

10. A. Ahmad, R. Ghufran, Z.A. Wahid, Effect of COD loading rate on an upflow anaerobic sludge blanket reactor during anaerobic digestion of palm oil mill effluent with butyrate,J. of Environ, Engi. Lands. Manage, 20, 256–264, (2012).

11. A. Ahmad, A novel application of red mud-iron on granulation and treatment of palm oil mill effluent using upflow sludge blanket reactor.Environmental TechnologyDOI:10.1080/09593330.2014.919034. (2014).

12. W. Parawira, J.S. Read, B. Mattiasson, L. Björnsson, Energy production from agricultural residues: high methane yields in pilot scale two-stage anaerobic digestion,Biomass Bioenergy, 32, 44–50, (2008).

13. J.B. Davis, Palm oil mill effluent: a review of methods proposed for its treatment,Tropical Science,20, 233–262, (1978).

14. j . o . Edewor比较fo的治疗方法r palm oil mill effluent (POME) wastes,Journal of Chemical Technology Biotechnology,36: 212–218, (1986).

15. P. Agamuthu, Palm oil mill effluent e treatment and utilization. In: Sastry CA, Hashim MA, Agamuthu P, (Eds.). Waste Treatment Plant , New Delhi: Narosa Publishing House, 1995.

16. M. Tabatabaei, M.R. Zakaria, R.A. Rahim, A.D.G. Wright, Y. Shirai, N. Abdullah, K. Sakai, S. Ikeno, M. Mori, M. Kazunori, A. Sulaiman, M.A. Hassan, PCR-based DGGE and FISH analysis of methanogens in an anaerobic closed digester tank for treating palm oil mill effluent,EleCRonic J. of Biotechnology, 12(3), 717-3458, (2009).

17. A.L. Ahmad, M.F. Chong, S. Bhatia, Mathematical modelling of multiple solutes system for reverse osmosis process in palm oil mill effluent (POME) treatment,Chemical Engineering Journal,132, 183–193, (2007).

18. A. Ahmad, R. Ghufran, Z.A. Wahid, Role of calcium oxide in sludge granulation and methanogenesis for the treatment of palm oil mill effluent using UASB reactor,J. of Hazardous Material,198, 40-48, (2011a).

19. M.A.I. Karim, L.L. Hie, The use of coagulating and polymeric flocculating agents in the treatment of palm oil mill effluent (POME),Biological Wastes, 2, 209–218, (1987).

20. A. Ahmad, R. Ghufran, Z.A. Wahid, Bioenergy from anaerobic degradation of lipid,Revie. Environ. Sci. and Biotechnol.DOI: 10.1007/s11157-011-9253-8, 2011b.

21. M. VLAD, À. CHIRIAC, S. CONSTANTINESCU, S. BALTA. Removal of the Pollutants from Wastewater through Coagulation-flocculation Process. Journal of Environmental Protection and Ecology V12, No 3A, 1517–1524, (2011).

22. S. Yacob, Y. Shirai, M.A. Hassan, M. Wakisaka, S. Subash, Start-up operation of semi-commercial closed anaerobic digester for palm oil mill effluent treatment,Process Biochemistry,41, 962–964, (2006).

23. A. Damayanti, Z. Ujang, M.R. Salim, G. Olsson, A.Z. Sulaiman, Respirometric analysis of activated sludge models from palm oil mill effluent.Bioresour. Technology,101, 144–149, (2010).

24. B.J. Wood, A review of current methods for dealing with palm oil mill effluent, The Planter. 53, 477–495, (1995).

25. A.D. Eaton, L.S. Clesceri, A.E. Greenberg, Standard Methods for the Examination of Water and Wastewater. Washington, DC: American Public Health Association, 1995.

26. American Public Health Association (APHA).Standard Methods for the examination of Water and Wastewater, 19thEd. Washington, D.C.; (1995).

27. Y.T. Wu, M.A. Wahab, J.M. Jahim, N. Anuar, Pollution control technologies for the treatment of palm oil mill effluent (POME) through end-of-pipe processes,J. of Environ. Management,91, 1467–1490, (2010).

28. M.A. Hassan, S. Yacob, Y. Shirai, Y.T. Hung, Treatment of Palm Oil Wastewaters. In: Handbook of Industrial and Hazardous Wastes Treatment. Wang, L.K., Y. Hung, H.H. Lo and C. Yapijakis (Eds.). New York: Marcel Dekker, ISBN: 0824741145, 2004.

29. G. Mosoarca, A. Negrea, Studies Regarding the Effects of Settling Tanks Sludge Recycling on Organic Matter Concentration from Treated Water.Journal of Environmental Protection and Ecology13, 198–202 (2012).

30. B. Negreanu-Pirjol,T. Negreanu-Pirjol, N. Badea, G. M. Parachiv, E. Gorun, R. Sirbu, A. Meghea, Physicochemical and Microbiological Characterisation of Municipal Sludge from Romanian Black Sea Coast Wastewater Treatment Plants.Journal of Environmental Protection and Ecology13, 2232–2239 (2012).

31. A. Ahmad, A.A. O-aljasser, Anaerobic Nitrogen, Sulfide and Carbon Removal in Anaerobic Granular Bed Reactor.Environ. ProgressDOI 10.1002/ep.11882 (2013).

32. A.W. Zularisam, A. Ahmad, M. Sakinah, A.F. Ismail, T. Matsuura, Role of natural organic matter (NOM), colloidal particles, and solution chemistry on ultrafiltration performance,Separat. and Purifica. Technol,78, 189–200 (2011).

33. M.A. Latif, R. Ghufran, Z.A. Wahid, A. Ahmad, Effect of Temperature and Organic Loading Rate on Upflow Anaerobic Sludge Blanket Reactor (USBR) by Treating Liquidized Food Waste,Environ. Progress,3, 114–121, (2011).

34. B. Zainuri, A. Sulaiman, M.A Hassan, Y. Shirai, S. Abd-Aziz, S. Yacob, M. Wakisaka, Improved anaerobic treatment of palm oil mill effluent in a semi-commercial closed digester tank with sludge recycling and appropriate feeding strategy.Pertanika J. Tropical Agriculture Science, 33(1), 27–37, (2010).

35. T. Setiadi, Husaini, A. Djajadiningrat, Palm oil mill effluent treatment by anaerobic baffled reactors: Recycle effects and bio-kinetics parameters,Water Science Technology.34, 59-66, (1996).

36. M. Faisal, H. Unno, Kinetic analysis of palm oil mill wastewater treatment by a modified anaerobic baffled reactor,Biochemical Engineering Journal9, 25-31 (2001).

37. R. Borja, C.J. Banks, B. Khalfaoui, A. Martin, Performance evaluation of an anaerobic hybrid digester treating palm oil mill effluent,J. of Environ. Scie. and Health., 31, 1379-1393 (1996a).

38. S.B. Thakre, L.B. Bhuyar, S.J. Deshmukh, Effect of different configurations of mechanical aerators on oxygen transfer and aeration efficiency with respect to power consumption,World Academy of Science Engine and Technology,38, (2008).

39. E. U. Cokgor, G. Insel, E. Aydin, D. Orhon, Respirometric evaluation of a mixture of organic chemicals biodegradation kinetics,J. of Hazard. Material161, 35–41 (2009).

40. A. Ahmad, Calcium oxide cement kiln dust for granulation of palm oil mill effluent, U.S. Patent No. 20120285884A1, (2012).

41. L. Singh, Z.A. Wahid, M.A. Siddiqui, A. Ahmad, M. Hasbi Ab-Rahim M. Sakinah, Application of immobilized upflow anaerobic sludge blanket reactor using Clostridium LS2 for enhanced biohydrogen production and treatment efficiency of palm oil mill effluent, 38, 5, 2221–2229 (2013).
