Introduction

Soil and environment are under tremendous pressure due to industrial expansion and discharge of effluents. During the past few decades industrial activities have increased greatly with rapid economic growth, this accomplished severe environmental pollution. Textile industry is a diverse sector in terms of raw materials, processes, products and equipment and has a very complicated industrial chain. Its biggest impact on the environment is related to primary water consumption (80–100 m³/ton of finished textile) and waste water discharge (115–175 kg of COD/ton of finished textile, a large range of organic chemicals, low biodegradability, color and salinity). Therefore, reuse of the effluents represents an economical and ecological challenge for the overall sector¹. The textile effluents have a high concentration of salts, through their accumulation in different trophic levels of ecosystem ultimately cause serious environmental impact in the neighboring receptors like agricultural land and water bodies².

Salinity is one of the major abiotic constraints, manifesting as osmotic stress at an early phase and ionic stress at later phases of plant growth, consequently affecting plants survival mechanisms at cellular, tissue and whole plant level^3,4. More than 45 million hectares of irrigated land are affected by salt which account for 20% of total land and 1.5 million ha of land are taken out of production each year owing to high salinity levels^5,4. So, it is essential to reclaim the contaminated soil by natural way of using plants. Among the many feasible techniques, phytoremediation is a cost-effective and environmentally sound technology for remediation of salt affected sites.

Sesuvium portulacastrum(l),家庭成员Aizoaceae,是不rtant halophyte in the category of “salt accumulator” plants which accumulates high salt concentration in their cells and tissues and overcomes salt toxicity by developing succulence. This plant has a distinct molecular and physiological flexibility that enables it to adapt and survive under various abiotic stress conditions^6-17. It has been observed that the growth characteristics ofSesuviumwere improved upon exposure to optimum NaCl concentrations (100 to 400 mM) under in vitro and an increase in growth rate and halosucculence status (200 mM of NaCl) under ex vitro conditions^{6,7,8,9,10,11}.

The ability ofS. portulacastrumto survive in adverse environmental conditions recognizes it as a possible candidate for the environmental protection^{12, 6, 8, 10, 13-17}.The evidence for the ability of this halophyte to desalinise an experimentally salinised agricultural soil (grown for 189 days) is provided⁷and confirmed the growth potentials of test cultureHordeum vulgare(barley) on the desalinised soil. There was a marked absorption of Na⁺ions by S. portulacastrum roots and their accumulation in the above-ground biomass up to 872 mg plant⁻¹and 4.36 g pot⁻¹(about 1 t ha⁻¹). Similarly in a study among six species of halophytes studies,S. maritimeandS. portulacastrumexhibited greater accumulation of salts in their tissues and higher reduction of salts in the saline land (upto 504 and 474 kg of sodium chloride respectively from the saline land from 1ha in 4 months time).Thus the characteristic feature ofSesuviumto accumulate high amount of salt in its tissues may be exploited for reducing salt levels in the potential agriculture soil and in the arid and semiarid regions by repetitive cultivation and harvesting of this plant in these areas. Hence, the present study aims to assess the phytoremediation potential ofSesuviumplant for the removal of salt from contaminated and salt enriched sites.

Materials and Methods

Sampling Location

Tamil Nadu textile city Tirupur, which has nearly 720 dyeing units, is ranked topmost in terms of generating hazardous waste. According to Tamil Nadu Pollution Control Board, an estimated 8,33,365.75 tons of hazardous waste is generated every year in Tirupur. Soil samples were collected from Andipalayam, Mangalam and Palayakottai villages of Tirupur District (Fig.1)

Soil sample collection

The Bulk soil samples were collected from dye and textile effluent contaminated sites, for conducting pot culture experiment. These villages represent the pollution status of Tirupur District and recorded high EC values (4.5 to 8.5 dSm^-1). The initial physico-chemical characteristics of the soils samples were analysed by standard operating procedures²².

Figure 1: Sampling Location Click here to View figure

Plant sample collection and identification

Pichavaram is the second largest Mangrove forest in the world. The salty marsh area of Pichavaram supports many halophytes.Sesuvium作为一个沿海工厂也作为一个内陆工厂and a mangrove associate and has shown to have nursing effects in mangroves. Salt hyper accumulating plantSesuvium portulacastrumsamples were collected for remediating the salt contaminated soils. The collected salt hyper accumulating plant was identified and confirmed asSesuvium portulacastrumthrough Botanical Survey of India and used to assess the salt removal potential. The chemical constituents of theSesuviumplant was analysed by standard operating procedures^{22, 26}. Scanning electron microscope image ofSesuvium portulacastrumwas also taken to observe the physiology of the plant (Fig.2).

Figure 2: Scanning Electron Microscope images ofSesuviumroot, leaves and shoot Click here to View figure

Experiment on salt uptake bySesuvium portulacastrum

Pot culture and field study on salt uptake in high EC soils of Andipalayam, Mangalam and Palayakottai villages of Tirupur District was conducted to check the salt uptake potential, growth and establishment ofSesuvium portulacastrumplants. At periodical intervals (Month intervals) the soil and plant samples were collected and analysed for physico-chemical characteristicsviz., pH, EC, Na, K, Ca and Mg, Cl and SO₄²³and the role played bySesuviumplants to remove the salt level. Observations reveal thatSesuvium portulacastrumis a proven plant for reclaiming salt affected soils.

Salt enrichment

Soil was enriched with different concentration (2000, 3000, 4000 and 5000 mg kg^-1) of NaCl. A control without any salt addition was maintained to study the salt uptake by the plants.Sesuvium portulacastrumplants were planted in the salt enriched soils and further observation on salt uptake, physico- chemical characteristics of soil and physiological changes in the plant were observed.

Statistical Analysis

The data on various characters studied during the investigation were statistically analysed by the method given by²⁴at a (P<0.05).

Results and Discussion

Establishment ofSesuvium portulacastrum在染料和纺织废水contaminated soils (Andipalayam, Mangalam and Palayakottai villages) of Tirupur District was observed and the growth of the plant was good in contaminated soil. At periodical intervals (Month) the soil and plant samples were collected and analysed for physico-chemical characteristics and the role played bySesuviumplants to remove the salt level was also studied (Fig 3 and 4).

Figure 3: Influence ofS. portulacastrum on soil EC and sodium Click here to View figure

The initial EC of the soil is 13.04 dSm^-1in Mangalam village and is reduced to 7.37 dSm^-1(30 DAP) and 5.34 dSm^-1(60DAP) (Fig. 3). In Andipalayam soil initial EC is 8.97 dSm^-1which decreased to 5.31 dSm^-1(30 DAP) and 3.29 dSm^-1(60DAP). In Palayakottai soil initial EC is 4.38 dSm^-1which decreased to 2.30 dSm^-1(30 DAP) and 1.24 dSm^-1(60DAP). The initial sodium content of the soil is 3372 mgkg^-1in Mangalam village is reduced to 820 mgkg^-1(30 DAP) and 643 mgkg^-1(60DAP) (Fig. 3). In Andipalayam soil initial sodium content is 2412 mgkg^-1and decreased to 558 mgkg^-1(30 DAP), 365 mgkg^-1(60DAP). In Palayakottai soil initial sodium content is 1500 mgkg^-1埃及和减少到539g^-1(30 DAP), 361 mgkg^-1(60DAP).

At periodic intervals the role played bySesuviumplants to remove the salt level was also studied by analyzing the plant characteristics such as pH, EC, Na, K, Ca and Mg (Fig. 4).

Figure 4: Salt accumulation inS. portulacastrum Click here to View figure

The initial EC of theS. portulacastrumplant collected from Pitchavaram is 12.09 dSm^-1which increased to 19.93 dSm^-1in Mangalam village soil (30 DAP), 19.87 dSm^-1in Andipalayam village soil (30 DAP) and 17.59 dSm^-1in Palayakottai village soil (30 DAP). The initial sodium content of theS. portulacastrumplant is 3.2% which increased to 4.4% in Mangalam village soil (30DAP), 3.7% in Andipalayam village soil (30 DAP) and 3.5% in Palayakottai village soil (30 DAP) (Fig. 4). On comparing, it is found that the uptake of salts bySesuviumplants collected from Pitchavaram was high in soil from Mangalam village than other village soils- Na: 3.2% to 4.4%, K: 1.2% to 1.5%, Ca: 0.06% to 0.14%, Mg: 0.05% to 0.24%. The evidence for the ability of this halophyte to desalinize an experimentally salinised agriculture soil is provided⁷and confirmed the growth potentials of test cultureHordeum vulgareon the desalinized soil. There was a marked absorption of Na⁺ions byS. portulacastrumroots and their above ground biomass up to 872 mg plant^-14.36 g pot^-1. Thus the characteristic feature ofSesuviumto accumulate high amount of salts in its tissue may be exploited for reducing salt levels in the potential agricultural soil and in the arid and semi arid regions by repetitive cultivation and harvesting of this crop in these areas²¹.

Salt enrichment study

Sesuvium portulacastrumplants were planted in the salt enriched soils and further observation on salt uptake, physico- chemical characteristics of soil and physiological changes in the plant were observed.

The EC of the soil was found to considerably decrease throughout the study period of 90 days at four increasing concentrations of Na salt (Table 1). At a NaCl concentration of 2000 mgkg^-180% reduction in soil EC was seen in 90 days interval. The highest EC reduction was observed in soil enriched with 4000 mgkg^-1of salt upto 82.5 % on the 90^thday. It was also observed that among the four different concentrations of salt enriched soil, the EC reduction was upto 50.6% in the soil enriched with 4000 mgkg^-1NaCl compared to other salt concentrations.Sesuviumplants established in salt enriched soils favored salt uptake which was evident in the decrease in Na in the soil (Table 1). The highest salt removal was seen in soil enriched with 3000 mgkg^-1of NaCl salt upto 81.82% in 90 days next to which 77.4% removal was observed in soil enriched with 2000 mgkg^-1of NaCl salt. Fifty seven percent salt removal was observed within a span of 30 days in soil enriched with 3000 mgkg^-1of NaCl salt whereas approximately 45-49% removal was seen in other concentrations.

Table 1: EC and Sodium content of the soil in salt enrichment experiment

Sesuviumplants established in salt enriched soils exhibited improved growth which was estimated in terms of shoot, root length (cm) and plant biomass (gpot^-1) (Table 2). Root length of the plants increased from an average of 10.8 cm to 38.15 cm in 90 days. 73.9 and 73.8% increase in root length was seen in soil enriched with 2000 mgkg^-1and 5000 mgkg^-1in 90 days. respectively. Similarly, a 73.7% increase in shoot length was observed in soil enriched with 2000 mgkg^-1salt whereas 72.1 % increase was seen in 5000 mgkg^-1salt enriched soil in 90 days. Regarding plant biomass, a 94.32 % increase was seen in plants grown in 5000 mgkg^-1salt enriched soil in 90 days which indicates increased succulence in the presence of salt..

Table 2: Growth parameters ofSesuvium portulacastrumin salt enrichment experiment

Analysis of soil and plant samples revealed that the plants were efficient in salt uptake from enriched soils. The electrical conductivity and sodium content were decreased inSesuviumgrown soil enriched with different concentrations of Na. 77.8% of Sodium was removed from the soil in a span of 90 days. The two halophytesS. maritimeandS. portulacastrumwere reported to exhibit greater accumulation of salts in their tissues and high reduction of salts in the saline land and particularly, they could remove 504 and 474 kg of NaCl from the saline land from 1 ha in 4 months³⁷.Decrease in soil EC and Na were reported¹⁷when three halophytesSesuvium portulacastrumL.,Arthrocne mumindicumandSuaeda fruticosaL. were used for reclaiming salt affected soils. According to them, with regards to biomass production, shoot sodium concentration and the pot area,Sesuvium portulacastrumcan extract 14 % of the salt that exists in the horizon 0-1 m of a soil having 10 % water and a salt concentration that exceeds 200 mMNaCl. Also, considerable increase in root and shoot length and biomass ofS. portulacastrumplants were observed throughout the study period.Sesuviumcan optimally uptake saline ions and carbon resources from the medium and allocate it to different parts of the plant resulting in increase succulence subsequently improving the growth, biomass and net photosynthesis rate of the plant^{6,7, 15, 20, 25-27, 28-34}.Sesuviumplants accumulate the inorganic salts in the vacuole, mainly NaCl and organic solutes in the cytoplasm. Na+ uptake into vacuoles requires Na+/H+ antiporters in the tonoplast and H+ ATPases and perhaps PPIases to provide the proton motive force. Halophytes vacuoles may have a modified lipid composition to prevent the leakage of Na+ back to the cytoplasm¹².

Conclusion

Sesuvium portulacastrumis a salt hyper accumulating halophyte which compartmentalizes the toxic Na⁺在液泡,因此膜结合反式port system regulating cytosolic ( Na⁺, K⁺and Ca⁺⁺) and ion accumulation by increasing the vacuolar volume. Environmentally, the plant’s potential has been checked for its survival under different abiotic stress conditions that includes salinity, drought and heavy metal accumulation which makesSesuviuma useful species as a heavy metal pollution indicator and for predicting soil salinity. Thus the characteristic feature ofSesuviumto accumulate high amount of salt in its tissues may be exploited for reducing salt levels in the potential agriculture soil and in the arid and semiarid regions by repetitive cultivation and harvesting of this plant in these areas.

Acknowledgement

The authors are acknowledged to the Department of Environmental Sciences, TamilNadu Agricultural University, Coimbatore for carried out this research work.

References

1. Emongor, V., Nkegbe, E., Kealotswe, B., Koorapetse, I., Sankwasa, S. andKeikanetswe, S. Pollution Indicators in Gaborone Industrial Effluent,Journal of Applied Sciences,5: 147-150 (2005).
2. Li Rosi O, Casarci M, Mattioli D, Florio L D, Best available technique for water reuse in textile SMEs,Desalination, 206: 614–619 (2007).
3. Bharti, P. K. andChauhan, A. Environmental Biotechnology and Application. Discovery Publishing House, New Delhi. India, p. 248 (2013).
4. Hasegawa, P. M., Bressan, R. A., Zhu, J. K. andBohnert, H. J. Plant cellular and molecular responses to high salinity.Annual Review of Plant Physiology and Plant Molecular Biology, 51:463–499 (2000).
5. Munns, R. and Tester, M. Mechanisms of salinity tolerance.Annual Review of Plant Biology,59: 651–681(2008).
6. Abdelly, C., Lachaal, M., Grignon, C., Soltani, A. and Hajji,M.Associationépisodiqued'halophytesstricts et de glycophytesdans un écosystèmehydromorphesalé en zone semi-aride,Agronomie, 15: 557-568 (1995).
7. Rabhi, M., Giuntini, D., Castagna, A., Remorini, D., Baldan, B., Smaoui, A., Abdelly, C. and Ranieri,A.Sesuviumportulacastrummaintains adequate gas exchange, pigment composition, and thylakoidproteins under moderate and high salinity.Journal of Plant Physiology,167(16): 1336-1341 (2010a).
8. Rabhi, M., Ferchichi, S., Jouini, J., Hamrouni, M. H., Koyro, H. W., Ranieri, A., Abdelly, C. andSmaoui, A.Phytodesalination of a salt-affected soil with the halophyteSesuviumportulacastrumto arrange in advance the requirements for the successful growth of a glycophytic crop,Bioresource Technology, 101:6822–6828 (2010b).
9. Lokhande, V. H., Nikam, T. D., Patade, V. Y. andSuprasanna, P. Morphological and molecular diversity analysis among the Indian clones ofSesuviumportulacastrum,Genetic Resources and Crop Evolution, 56:705–717 (2009a).
10. Lokhande, V. H., Nikam, T. D. andSuprasanna, P.Sesuviumportulacastrum(L.) L., a promising halophyte: cultivation, utilization and distribution in India.Genetic Resources and Crop Evolution, 56(5):741–747 (2009b).
11. Lokhande, V. H., Srivastava, S., Patade, V. Y., Dwivedi, S., Tripathi, R. D., Nikam, T. D. andSuprasanna, P. Investigation of arsenic accumulation and tolerance inSesuviumportulacastrum(L.) L.Chemosphere, 82(4): 529-534 (2010a).
12. Lokhande, V. H., Nikam, T. D. andSuprasanna, P. Biochemical, physiological and growth changes in response to salinity in callus cultures ofSesuvium portulacastrum,Plant Cell, Tissue and Organ Culture, 102:17–25 (2010b).
13. Lokhande, V. H., Nikam, T. D. andSuprasanna, P. Differential osmotic adjustment to iso-osmotic salt and PEG stress in vitro in the halophyteSesuviumportulacastrum,Journal of Crop Science and Biotechnology, 13(4):251–256 (2010c).
14. Lokhande, V. H., Nikam, T. D., Patade, V. Y., Ahire, M. L. andSuprasanna, P. Effects of optimal and supra-optimal salinity stress on antioxidative defense, osmolytes and in vitro growth responses inSesuviumportulacastrum,Plant Cell, Tissue and Organ Culture, 104:41–49 (2011a).
15. Lokhande, V. H., Srivastava, S., Patade, V. Y., Dwivedi, S., Tripathi, R. D., Nikam, T. D. andSuprasanna, P. Investigation of arsenic accumulation and tolerance inSesuviumportulacastrum(L.) L.Chemosphere, 82(4):529–534 (2011b).
16. Lokhande, V. H., Srivastava, A. K., Srivastava, S., Nikam, T. D. andSuprasanna, P. Regulated alterations in redox and energetic status are the key mediators of salinity tolerance in the halophyteSesuviumportulacastrum(L.) L.,Plant Growth Regulation, 65(2):287–298 (2011c).
17. Moseki, B. and Buru, J. C. Ionic and water relations ofSesuvium portulacastrum(L).Scientific Research and Essays, 5(1):35–40 (2010).
18. Zaier, H., Ghnaya, T., Lakhdar, A., Baioui, R., Ghabriche, R., Mnasri, M., Sghair, S., Lutts, S. andAbdelly, C. Comparative study of Pbphytoextraction potential inSesuviumportulacastrumandBrassica juncea: tolerance and accumulation.Journal of Hazardous Materials, 183(1-3): 609-615 (2010a).
19. Zaier, H., Mudarra, A., Kutscher, D., Fernandez de la Campa, M. R., Abdelly, C. andSanz-Medel, A. Induced lead binding phytochelatins inBrassica junceaandSesuviumportulacastruminvestigated by orthogonal chromatography inductively coupled plasma-mass spectrometry and matrix assisted laser desorption ionization-time of flight-mass spectrometry.AnalyticaChimicaActa, 671(1-2): 48-54 (2010b).
20. Short, D. C. and Colmer, T. D. Salt tolerance in the halophyteHalosarciapergranulatapergranulata.Annals ofBotany, 83:207–213 (1999).
21. Ghnaya, T., Nouairi, I., Slama, I., Messedi, D., Grignon, C., Abdelly, C. andGhorbel, M. H. Cadmium effects on growth and mineral nutrition of two halophytes:SesuviumportulacastrumandMesembryanthemumcrystallinum.Journal of Plant Physiology, 162(10):1133– 1140 (2005).
22. Standard methods for the examination of water and waste water, 21st edn. American Public Health Association, Washington, DC (2005)
23. Ghnaya, T., Slama, I., Messedi, D., Grignon, C., Ghorbel, M. H. andAbdelly, C. Effect of Cd2⁺on K⁺, Ca⁺and N uptake in two halophytesSesuviumportulacastrumandMesembryanthe mumcrystallinum: Consequences on growth.Chemosphere, 67(1):72–79 (2007a).
24. Gomez, K.A. and Gomez. A. A.Statistical Procedures for Agricultural Research, John Wiley and Sons, New Delhi, p. 680 (1984).
25. Ravindran, K. C., Venkatesan, K., Balakrishnan, V., Cehllappan, K. P. and Balasubramanian, T. Restoration of saline land by halophytes for Indian soils,Soil Biology and Biochemistry, 39:2661– 2664 (2007).
26. Jackson, M. L.L.Soil Chemical Analysis.Prentice Hall of India (Pvt) Ltd., New Delhi, p.275 (1973).
27. Venkatesalu, V. andChellapan, K. P. Photosynthetic characteristics ofSesuviumportulacastrumunder salt stress,Photosynthetica, 28:313–316 (1993a).
28. Venkatesalu, V. andChellappan, K. P. Photochemical characteristics ofSesuvium portulacastrumunder sodium chloride stress,Photosynthetica, 29:139–141(1993b).
29. Messedi, D., Labidi, N., Grignon, C. andAbdelly, C. Limits imposed by salt to the growth of the halophyteSesuviumportulacastrum,Journal of Plant Nutrition and Soil Science, 167:720–725 (2004).
30. Ghnaya, T., Slama, I., Messedi, D., Grignon, C., Ghorbel, M. H. andAbdelly, C. Cd-induced growth reduction in the halophyteSesuviumportulacastrumis significantly improved by NaCl.Journal of Plant Research, 120:309–316 (2007b).
31. Slama, I., Messedi, D., Ghnaya, T., SavouÅ•e, A. andAbdelly, C. Effects of water-deficit on growth and proline metabolism inSesuviumportulacastrum,Environmental and Experimental Botany, 56:231–238 (2006).
32. Slama, I., Ghnaya, T., Hessini, K., Messedi, D., Savoure, A. andAbdelly, C. Comparative study of the effects of mannitol and PEG osmotic stress on growth and solute accumulation inSesuviumportulacastrum,Environmental and Experimental Botany, 61:10–17 (2007a).
33. Slama, I., Ghnaya, T., Messedi, D., Hessini, K., Labidi, N., Savoure, A. andAbdelly, C. Effect of sodium chloride on the response of the halophyte speciesSesuviumportulacastrumgrown in mannitol-induced water stress,Journal of Plant Research, 120:291–299 (2007b).
34. Slama, I., Ghnaya, T., SavouÅ•e, A. andAbdelly, C. Combined effects of long-term salinity and soil drying on growth, water relations, nutrient status and proline accumulation ofSesuviumportulacastrum,ComptesRendusBiologies, 331:442–451 (2008).
